Shrink Packaging Machines
High Speed Fully Automatic Side Seal Packing Machine APSS-5022 / 7522 / 10022
Feature
- Constant heated sealing blades can perform continuously, which enables no limit of product length and high capacity of up to 60 bags per minute.
- Auto photocell infeed system provides both horizontal and vertical choices to suit various product sizes.
- Product changeovers can be easily realized by hand wheel adjustments, no elements need to be replaced.
- Machine produces an enclosed pack with sealing on 3 sides.
- Applicable for PE, POF and other center-folded shrink films, especially for POF shrink film packing.
- Automatic Waste Strip wind up design.
- Motor-driven infeed conveyor and free roller Outfeed conveyor are options for fully automatic application.
Options:
- Kissing belt (suitable for small, irregular products)
- Printing Film Photo sensor
- 1 .5M infeed conveyor
- Automatic Product Pusher
- 3 meters length lugs pushing conveyor
| Model No. | APSS-5022 | APSS-7522 | APSS-10022 |
| Power Supply | 220V/1PH, 3000W | 380V/3PH, 4000W | 380V/3PH, 5000W |
| Air Supply | 6 bar, 10L/min | 6 bar, 10L/min | 6 bar, 10L/min |
| Sealing bar width | 500mm | 750mm | 1000mm |
| Max. pack height | 220mm | 220mm | 220mm |
| Sealing jaw driven by | Servo motor | Servo motor | Servo motor |
| Max. conveyor speed | 35m/min | 35m/min | 35m/min |
| Max. packing speed | 70ppm | 50ppm | 40ppm |
| Center seal function | Yes | Yes | Yes |
| Machine size | 2130x1697x1722mm | 2404x2153x1722mm | 2603x2110x1720mm |
| Packing size | 2210x2020x1720mm | 2660x2110x1720mm, 1660x960x1170mm |
2660x2110x1720mm & 1600x960x1170mm |
| Machine weight | 760/1000kg | 820/1136kg, 90/120kg |
1040/1330kg & 152/200kg |
| Model No. | APSS-4015E | APSS-7030E |
| Power Supply | 220V/1PH, 2000W | 220V/1PH, 2500W |
| Air Supply | 6 bar, 30L/min | 6 bar, 30L/min |
| Sealing bar width | 400mm | 700mm |
| Max. pack height | 150mm | 300mm |
| Sealing jaw driven by | Cylinder | Cylinder |
| Max. conveyor speed | 35m/min | 35m/min |
| Max. packing speed | 50ppm | 30ppm |
| Center seal function | Yes | Yes |
| Machine size | 1582x1500x1722mm | 2404x2050x1722mm |
| Packing size | 1810x1610x1720mm | 2480x2080x1720mm, 1460x600x620mm |
| Machine weight | 630/770kg | 800/1110kg, 90/120kg |
Special size can be customer made
Application
Software, food, cosmetics, printing, pharmaceutical, flooring, ceramics, beverage, metal, plastics and other industries large quantities of shrink wrap. Suitable for OPP, POF, PE, PVC and other shrink packaging materials.
