Features
1. PLC with Index Gear Conveyor, Inverter Speed Control and Touch Screen Operation.2. Stainless Steel frame and Anodized Aluminum.
3. Three models for Film Feeding: Sensor, Encoder, Timer. Available for Colorful & Blank film.
4. Sealing and Boarded Cutting (Profile cut).
5. Product track Output.
Specification
| Model | ET-22S | ET-22M |
| Power | 220/380/450V | 220/380/450V |
| Capacity(psc/hr) | 1000~2000 | 2000~4000 |
| Max.Cup Size(mm) | 220x170x100 | 440x220x100 |
| Machine Size(mm) WxDxL | 2000x660x1700 | 2000x930x1700 |
| Information above for sample only, we can offer for Customer's Requirement also. |
Application
1. Suitable for beverages, pudding, jelly, fast-food, snacks, various prepared foods for microwave, seasoned frozen food, pickled foods, seafood and processed agricultural products etc. which load into the cup and tray.2. Sealable material: PP, PE, PS, PET, HDPE, EPS, PSP, metalized aluminium foil, paper box, etc.
Optional Function
1. Auto tray drop.2. Auto filling: Liquid, heavy liquid or solid products.
3. MAP gas flushing: ET-22 only.
4. Pre-cut lid application.
5. Product output discharger.
6. Lid capping.
7. Interchangeable base mould for sealing tool.
8. Date Printer/Coder (Hot ink manual, Times Roman 12 font, 5 rows x 9 alphanumeric lines)
9. Weightier.
